160 - 260 m2 (1,615 - 2,798 sqft) 3-BEDROOM GROUND LEVEL UNITS
Below you will find a collage of all of our 1-bedroom units, from 160 m2 (1,615 sqft) to 260 m2 (2,798 sqft), all shown in a series of 4. If you find a model of your choice you may click on the model name to view the drawings of the model. These model pages show the floor plans and the side elevations which can all be enlarged. The dimensions are given for the model itself plus the areas of the bathrooms, bedrooms, kitchens, the total-sided area, the deck area, and the required building space. The mentioned-sided area is the net interior floor area and does not include the area of a deck or balcony. This is mentioned separately. The index (K) denotes that a kitchen or kitchenette is available upon your choice. Changes to the interior as per your requirements are possible.
HELIANTHUS
CODE C-3
Total net. interior sided area:
Ground floor: 217 m2 (2,336 sqft),
2nd floor: 121.7 m2 (1,310 sqft)
Deck area: Ground floor: No deck, 2nd floor: 7 m2 (75 sqft)
HYACINTH
CODE C-2
Total net. interior sided area:
Ground floor: 219.3 m2 (2,077 sqft),
2nd flloor: 117.1 m2 (1,260 sqft)
Deck area: Ground floor front: 5 m2 (54 sqft), left side: 9 m2 (97 sqft),
2nd floor right side: 22.3 m2 (240 sqft), rear: 7.4 m2 (80 sqft), left side: 39.5 m2 (425 sqft)
TEPAK DARAH
CODE D-5
Total net. interior sided area:
Ground floor: 226.8 m2 (2,441 sqft),
2nd floor: 74.6 m2 (803 sqft)
Deck: 67 m2 (721 sqft), 2nd floor left side: 31.3 m2 (337 sqft), right side: 24.2 m2 (260 sqft)
